STS Low-Temperature Stability Chamber, Adopt the latest structural design, select the original imported high quality parts and manufacturing process, ensure the long-term continuous operation of the equipment, stable and reliable performance, suitable for temperature sensitive medicine stability test and preservation.
| Model | 150RC | 250RC | 400RC | 800RC | 150FC | 250FC | 400FC | 800FC | |
Test Space Dimensions(mm) | W（wide） | 600 | 600 | 600 | 1200 | 600 | 600 | 600 | 1200 |
| H（high） | 630 | 830 | 950 | 1360 | 630 | 830 | 950 | 1360 | |
| D（deep） | 405 | 500 | 700 | 490 | 405 | 500 | 700 | 490 | |
Exterior Housing Dimensions(mm) | W（wide） | 760 | 760 | 760 | 1360 | 760 | 760 | 760 | 1360 |
| H（high） | 1500 | 1650 | 1750 | 1960 | 1500 | 1650 | 1750 | 1960 | |
| D（deep） | 830 | 870 | 1060 | 850 | 830 | 870 | 1060 | 850 | |
| Temperature Range(℃ ) | 5 | -20 | |||||||
| Capacity (L) | 150 | 250 | 400 | 800 | 150 | 250 | 400 | 800 | |
| Power(KW) | 0.5 | 0.6 | 1.0 | 1.5 | 1.0 | 1.5 | 2.0 | 2.5 | |
| Shelf | 3 | 3 | 3 | 4 | 3 | 3 | 3 | 4 | |
| Remark | Single Door | Single Door | Single Door | Double Door | Single Door | Single Door | Single Door | Double Door | |
1. The newly airway system designed achieves uniform of temperature and humidity form different parts inside the chamber; Polyurethane foam technology is adopted, with good heat preservation performance
2. Imported fully enclosed industrial compressor, high efficiency, low noise, long life
3. The liner is made of mirror stainless steel 304, no pollution source, easy to clean
4. Have an alarm system in line with GMP requirements; Gmp-compliant data acquisition system, standard needle printer and USB flash drive storage
5. Safety device: Compressor overheat and overpressure overload protection
6. Alarm system: acoustic and optical alarm for temperature deviation on site, standard remote SMS alarm (with power failure alarm), multiple devices can share one mobile phone card
7. Optional electronic record system, three-level user permissions, audit tracking function
8. Meet ICH 2003、Pharmacopoeia 2015 edition, Executive Standard GB/T 10586-2006
9. Frosting device: Automatic frosting device
10. Temperature Fluctuation: ≤ ±1.0℃; Temperature Deviation: ≤ ±2.0℃
11. Power: AC 220 V±10% 50 HZ；Environment temperature: +5 ～ 35℃
