2 ZONE THERMAL SHOCK CHAMBER

The traditional approach: two temperature methods, specimen moving with the basket. STS models – Vertical chambers with 2 compartments corresponding to 2 different temperature levels.is supplied with a motorized system connected by a screw rod for the transfer of the specimen between the hot and cold compartments.

Model

STSII 60-40WSTSII 125-40WSTSII 200-40WSTSII 300-40WSTSII 60-55WSTSII 125-55WSTSII 200-55WSTSII 300-55WSTSII 60-65WSTSII 125-65WSTSII 200-65WSTSII 300-65W

Test space dimensions(mm)

W(wide)400 470 770 770 400 470 770 770 400 470 770 770
H(high)370 410 610 610 370 410 610 610 370 410 610 610
D(deep)430 650 450 650 430 650 450 650 430 650 450 650

Overall Dimensions(mm)

W(wide)860 875 1190 1190 860 875 1190 1190 860 875 1190 1190
H(high)2000 2000 2400 2400 2000 2000 2400 2400 2000 2000 2400 2400
D(deep)2050 2250 2250 2450 2050 2250 2250 2450 2050 2250 2250 2450



Temperature specification

Preheat and precool temperaturePreheating :(ambient~150)℃; Precooling:(-70 ~ ambient)℃
Temperature recovery/switching timeRecovery time: 2~5min; Switching time: ≤10s
Temperature deviation(℃)±2.0℃

Weight specification

Weight(kg)880 950 1100 1300 910 980 1300 1500 950 1100 1500 1700
Max weight of sample(kg)20 50 70 80 20 50 70 80 20 50 70 80
Exposure timeHigh temperature exposure: 30 min; Low temperature exposure: 30 min
Capacity(L)60 125 200 300 60 125 200 300 60 125 200 300
Max current(A)30 42 47 52 42 42 55 65 47 47 65 72
Power supply(kW)20 20 25 30 23 23 34 45 26 26 45 55
Cooling water flow(t/h)13 10 14 16

ambient

Features:

1. Capacitive Multi-Touch-Display in the front
2. USB-Connection to save measuring data on USB Stick
3. Ethernet-Interface
4. Door with window, incl. LED-light
5. Porthole*2
6. Shelf, stainless steel
7. Entry port, size depending on chamber type
8. Single-hand operated door handle, lockable
9. Air dryer system to avoid freezing in long-time testing
10. Low consumption data
11. Minimum noise level
12. User-friendly operation and programming
13. Temperature measuring with Pt 100 in air inlet and air outlet
14. Service-friendly construction
15. International standards are fulfilled
16. Compact design with small installation area

Accessories:

1. Shelves and protection for the basket
2. Increased temperature range in hot chamber to +250°C (for 130 ltr.)
3. Temperature protection for test specimen
4. Pt 100 for temperature measuring on test specimen
5. CID software for programming and documentation
6. Water cooled &air cooled
7. Entry ports
8. Higher test load
9. Other interfaces: RS232, RS485 and USB
