With our thermal shock series, extremely fast temperature changes in the range from -70 °C to +220 °C can be realised. For this purpose, we offer solutions in the form of the damper shock test chamber, with stationary test space and including the ambient temperature for 3-zone tests. So that you can reduce early failures and increase the reliability of your products. Reproducible, certified and time-lapse.
Model | STSIII 70-40W | STSIII 150-40W | STSIII 200-40W | STSIII 300-40W | STSIII 70-55W | STSIII 150-55W | STSIII 200-55W | STSIII 300-55W | STSIII 70-65W | STSIII 150-65W | STSIII 200-65W | STSIII 300-65W | |
Test space dimensions(mm) | W（wide） | 410 | 650 | 650 | 970 | 410 | 650 | 650 | 970 | 410 | 650 | 650 | 970 |
| H（high） | 460 | 460 | 460 | 460 | 460 | 460 | 460 | 460 | 460 | 460 | 460 | 460 | |
| D（deep） | 370 | 500 | 670 | 670 | 370 | 500 | 670 | 670 | 370 | 500 | 670 | 670 | |
Overall Dimensions(mm) | W（wide） | 860 | 875 | 1190 | 1190 | 860 | 875 | 1190 | 1190 | 860 | 875 | 1190 | 1190 |
| H（high） | 2000 | 2000 | 2400 | 2400 | 2000 | 2000 | 2400 | 2400 | 2000 | 2000 | 2400 | 2400 | |
| D（deep） | 2050 | 2250 | 2250 | 2450 | 2050 | 2250 | 2250 | 2450 | 2050 | 2250 | 2250 | 2450 | |
Temperature specification | Preheat and precool temperature | Preheating :(60~200) ℃; Precooling:(-80 ~ 0) ℃ | |||||||||||
| Temperature recovery/switching time | Recovery time: 5min; Switching time: ≤10s | ||||||||||||
| Temperature deviation(℃) | ±2.0℃ | ||||||||||||
| Exposure time | High temperature exposure: 30 min; Low temperature exposure: 30 min | ||||||||||||
Weight specification | Weight(kg) | 980 | 1050 | 1400 | 1500 | 1400 | 1450 | 1480 | 1510 | 1430 | 1480 | 1680 | 1790 |
| Max weight of sample(kg) | 2.8 | 7.8 | 7.8 | 7.8 | 2.8 | 7.8 | 7.8 | 7.8 | 2.8 | 7.8 | 7.8 | 7.8 | |
| Test method | The pneumatic door switches between high temperature and low temperature | ||||||||||||
| Capacity（L) | 70 | 150 | 200 | 300 | 70 | 150 | 200 | 300 | 70 | 150 | 200 | 300 | |
| Max current(A) | 40 | 45 | 60 | 60 | 59 | 59 | 63 | 63 | 63 | 63 | 85 | 95 | |
| Power supply(kW) | 26 | 29 | 37 | 37 | 37 | 37 | 38 | 38 | 38 | 38 | 53 | 58 | |
| Cooling water flow(t/h) | 2.8 | 3 | 3 | 3 | 5 | 5 | 6 | 6 | 8 | 10 | 15 | 15 | |
1. Capacitive Multi-Touch-Display in the front
2. USB-Connection to save measuring data on USB Stick
3. Ethernet-Interface
4. Door with window, incl. LED-lightg
5. Porthole * 2
6. Air dryer system to avoid freezing in long-time testing
1. Shelves
2. Increased temperature range in hot chamber to +250°C
3. Temperature protection for test specimen
4. Pt 100 for temperature measuring on test specimen
5. CID software for programming and documentation
6. Water cooled &air cooled
7. Entry ports
8. Higher test load
9. Other interfaces: RS232, RS485 and USB
