STS-DHP Electric Heating Thermostatic Incubator, It is used for bacteria culture, fermentation and constant temperature test in medical and health, pharmaceutical industry, biochemistry, agricultural science and other scientific research and industrial production departments.
| Model | 9052DHP | 9082DHP | 9162DHP | 9272DHP | 9402DHP | 9602DHP | |
Test Space Dimensions(mm) | W（wide） | 415 | 500 | 500 | 600 | 640 | 840 |
| H（high） | 355 | 400 | 650 | 750 | 1355 | 1355 | |
| D（deep） | 360 | 400 | 500 | 600 | 585 | 600 | |
Exterior Housing Dimensions(mm) | W（wide） | 690 | 780 | 790 | 890 | 780 | 980 |
| H（high） | 500 | 560 | 810 | 910 | 1880 | 1880 | |
| D（deep） | 500 | 530 | 630 | 740 | 750 | 800 | |
| Temperature Range(℃ ) | RT+5 ～ 65 | ||||||
| Capacity (L) | 50 | 80 | 160 | 270 | 400 | 600 | |
| Power(KW) | 0.3 | 0.4 | 0.6 | 0.8 | 1.1 | 2.2 | |
| Shelf | 2 | 2 | 2 | 2 | 3 | 4 | |
1. The newly airway system designed achieves uniform of temperature and humidity form different parts inside the chamber; Insulation layer with glass fiber filling technology, high temperature resistance, good insulation
2. Liner is brushed stainless steel material, four corners half circle arc over plating, shelf can be free loading and unloading.
3. Special temperature controller, sensitive induction, small system error
4. Power: AC 220 V±10% 50 HZ; Environment temperature: +5 ～ 35℃
5. Optional printer or RS485 interface, it can be connected to the printer or computer
6. With built-in glass door, it is convenient to observe the changes of culture directly
7. Temperature Resolution: 0.1℃; Temperature Fluctuation: ±0.5℃; Temperature Uniformity: ±1.5℃; (The test point is 37℃ )
8.Power: AC 220 V±10% 50 HZ; Environment Temperature: +5 ～ 35℃
